Specifications
Description
The Viega 29065 is a 1-1/4" check valve from Viega's MegaPress 316 system with Press x Press ends for stainless steel pipe (IPS sizes). It features a stainless steel 316 body. Rated to 0°F to 250°F.
Features
- Smart Connect Technology
- Stainless steel 316
- Press connection
- Inline
- Components EPDM sealing elements
Common Questions
- What pipe and press tool does this valve need?
- It installs with a MegaPress press jaw or ring, on stainless steel pipe (IPS sizes).
- Which sealing element is in the press ends?
- The press connections seal with EPDM sealing elements, which Viega rates from 0°F to 250°F.
Specifications
- Type: Check Valve
- Size: 1-1/4"
- Connection: Press
- Body Material: Stainless steel 316
- Country of Origin: Germany
- MPN: 29065
- Temperature: 0°F to 250°F
- Press Profile: MegaPress
- Size Basis: IPS
- Sealing Element: EPDM
- For Use On: Stainless Steel
- End Connections: Press x Press
Product Information
| SKU | Country of Origin |
|---|---|
| 29065 | Germany |
Dimensions
| Size Nominal | 1-1/4" | End Connection | Press |
Details
| Series | MegaPress 316 | Device Type | Check Valve |
| Body Material | Stainless steel 316 | Max Temp °F | 250.0 °F |
| Min Temp °F | 0.0 °F | Work material | Stainless Steel |
| End combination | Press x Press | — | — |
Compare with similar products
| Assembly Type | — | — | — | RPZ
| Dual Check
| — |
| Hazard Rating | — | — | — | High Health Hazard
| Low Health Hazard
| — |
| ASSE Standard | — | — | — | ASSE 1013
| ASSE 1012
| — |
| Test Cocks | — | — | — | 4
| 0
| — |
| Series | MegaPress 316
| 112-600XLHR
| PureFlow Press
| 112-975XL2
| 760
| MegaPress 316
|
| Country Of Origin | Germany
| — | Canada
| — | — | China
|
| Spec Sheet | — | — | — | |||
| Install Sheet | — | — | — | |||
| Device Type | Check Valve
| Water Pressure Reducing Valve with Removable Integral Strainer
| Stop Valve
| Backflow Preventer - Bronze Reduced Pressure Principle Assembly
| Dual Check Valve Backflow Preventer with Intermediate Atmospheric Vent
| Globe Valve
|
| Size Nominal | 1-1/4"
| 1-1/2"
| 3/8"
| 1-1/2"
| 3/4"
| 1"
|
| Outlet Size | — | 1-1/2"
| 1/4" OD
| — | — | — |
| Lead Free | — | Yes | Yes | Yes | — | — |
| End Connection | Press
| FNPT
| PEX
| FNPT
| FNPT
| Press
|
| Body Material | Stainless steel 316
| Lead-Free Bronze
| Nickel-plated brass
| Bronze
| Brass
| 316 stainless steel
|
| Application | — | Domestic Water
| — | Domestic Water
| Domestic Water
| — |
| Max Pressure PSI | — | 300.0 psi | — | 175.0 psi | 175.0 psi | — |
| Max Temp °F | 250.0 °F | 140.0 °F | — | 180.0 °F | 210.0 °F | 250.0 °F |
| Certifications | — | ASSE-1003, IAPMO, CSA, NSF-61
| — | ASSE-1013, AWWA-C511, CSA-B64.4, C-UL, UL, USC, NSF-61, NSF-372, IAPMO
| ASSE-1012, CSA-B64.3
| — |
| Min Temp °F | 0.0 °F | — | — | — | — | 0.0 °F |
