The Viega 87610 is a 1" globe valve from Viega's MegaPress 316 system with Press x Press ends for stainless steel pipe (IPS sizes). It features a 316 stainless steel body. Rated to 0°F to 250°F.
Features
- For use with Sch. 5 to Sch. 40 stainless steel pipe
- Not suitable for fuel gas application
- 316 stainless steel body and press ends
- Press connections
- Components EPDM sealing element, aluminum ADC12 handwheel, stainless steel disc and stem
Common Questions
- What pipe and press tool does this valve need?
- It installs with a MegaPress press jaw or ring, on stainless steel pipe (IPS sizes).
- Which sealing element is in the press ends?
- The press connections seal with EPDM sealing elements, which Viega rates from 0°F to 250°F.
Specifications
- Type: Globe Valve
- Size: 1"
- Connection: Press
- Body Material: 316 stainless steel
- Country of Origin: China
- MPN: 87610
- Temperature: 0°F to 250°F
- Press Profile: MegaPress
- Size Basis: IPS
- Sealing Element: EPDM
- For Use On: Stainless Steel
- End Connections: Press x Press
Product Information
| SKU | Country of Origin |
|---|---|
| 87610 | China |
Dimensions
| Size Nominal | 1" | End Connection | Press |
Details
| Series | MegaPress 316 | Device Type | Globe Valve |
| Body Material | 316 stainless steel | Max Temp °F | 250.0 °F |
| Min Temp °F | 0.0 °F | Work material | Stainless Steel |
| End combination | Press x Press | — | — |
Compare with similar products
| Series | MegaPress 316
| MegaPress 316
| MegaPress FKM
| MegaPress 316
| MegaPress 316
| MegaPress 316
|
| Country Of Origin | China
| China
| China
| China
| China
| China
|
| Device Type | Globe Valve
| Globe Valve
| Globe Valve
| Globe Valve
| Globe Valve
| Globe Valve
|
| Size Nominal | 1"
| 1-1/2"
| 1"
| 1/2"
| 2"
| 3/4"
|
| End Connection | Press
| Press
| Press
| Press
| Press
| Press
|
| Body Material | 316 stainless steel
| 316 stainless steel
| 316 stainless steel
| 316 stainless steel
| 316 stainless steel
| 316 stainless steel
|
| Max Temp °F | 250.0 °F | 250.0 °F | 284.0 °F | 250.0 °F | 250.0 °F | 250.0 °F |
| Min Temp °F | 0.0 °F | 0.0 °F | 14.0 °F | 0.0 °F | 0.0 °F | 0.0 °F |
