Watts LFNLF9 3/8 Lead-Free Dual Check Valve Backflow Preventer

The Watts LFNLF9 3/8 is a 3/8" lead-free dual check valve, approved for low health hazard protection. It features a rubber seat. Rated to 150 psi and 33°F to 180°F. This model is certified lead-free for potable-water installations.

This 3/8 inch lead free dual check vacuum breaker backflow preventer for laboratory faucets prevents the reverse flow of polluted water from entering into the potable water supply where portable hoses can be attached. It is designed for health hazard non-continuous pressure applications. It consists of a chrome plated lead free body construction, dual check valves, stainless steel working parts, and durable rubber diaphragm and disc.

Features

• Lead free construction
• Chrome finish
• Faucet threads
• Compact design

Common Questions

What hazard level is this Dual Check approved for?

It is rated for low health hazard (non-toxic, "pollutant") cross-connections only. Where the substance downstream could be a health hazard, codes require a reduced pressure zone (RPZ) assembly instead. The assembly is listed to ASSE 1035.

Is this model legal for potable water?

Yes. It is certified lead-free to NSF/ANSI 372, which is what state plumbing codes require for any device in a drinking-water line.

Can this device be field tested?

No. It has no test cocks and is not a testable assembly, so it cannot be certified by a backflow tester. Where a jurisdiction requires an annually tested device, specify a testable assembly (double check, RPZ, or PVB) instead.

Specifications

• Type: Dual Check
• Size: 3/8"
• Inlet Size: 3/8"
• Outlet Size: 3/8"
• Seat / Seal Material: Rubber
• Max Pressure (psi): 150
• Application: Domestic Water
• Backflow Protection: Backpressure
• Operation: Continuous
• Pack Quantity: 50
• Country of Origin: Mexico
• Warranty: 1 Year Limited
• MPN: LFNLF9 3/8
• Temperature: 33°F to 180°F
• Certifications: ASSE-1035, CSA-B64
• Lead-Free: Yes
• Assembly Type: Dual Check
• Hazard Protection Level: Low Health Hazard
• ASSE Standard: ASSE 1035
• USC FCCCHR Approved: No
• Field Testable: No
• Number of Test Cocks: 0
• Shutoff Valves: None
• Flood Sensor (SentryPlus Alert): No
• Strainer Included: No
• Air Gap Fitting Included: No
