Watts LFN30 5-30 1/2 Lead-Free Relief Valve, Bronze, NPT

The Watts LFN30 5-30 1/2 is a 1/2" lead-free calibrated adjustable pressure relief valve for well system pressure relief service, field-adjustable over 5-30 psi. It features a bronze body. Rated to 75 psi. This model is certified lead-free for potable-water installations.

This 1/2 inch lead free pressure relief valve is used to protect against excessive pressures in well systems. This valve is designed for pressure relief only and is not diaphragm actuated. It consists of a lead free bronze body with NPT threaded male inlet and NPT threaded female (drain) outlet connections, and stainless steel spring. The adjustable pressure relief range is 5 to 30 psi.

Features

• Lead free bronze body construction
• Soft seated
• Spring loaded
• Automatic reseating

Common Questions

What pressure does this relieve at?

This is a calibrated valve — you set it. It adjusts over 5-30 psi, so it has no factory set point. Set it below the working pressure rating of the equipment you are protecting, and re-check the setting after installation.

Can I use this on potable water?

Yes. It is certified lead-free to NSF/ANSI 372, which is what plumbing codes require for any device in a drinking-water line.

Specifications

• Type: Relief
• Size: 1/2"
• Inlet Size: 1/2"
• Outlet Size: 1/2"
• Connection: NPT
• Body Material: Bronze
• Max Pressure (psi): 75
• Pack Quantity: 25
• Country of Origin: United States
• Warranty: 1 Year Limited
• MPN: LFN30 5-30 1/2
• Lead-Free: Yes
• Relief Type: Calibrated Adjustable
• Adjustment Range: 5-30 psi
• Application: Well System Pressure Relief
• Connection Configuration: MNPT inlet x FNPT outlet
• Automatic Reseating: Yes
• Approved for Potable Water: Yes
• SentryPlus Alert Flood Sensor: No
