Specifications
Description
The Watts LFF113FP 150-FP2 6 is a 6" lead-free globe-pattern reduced pressure zone (RPZ) backflow preventer with Flanged connections. It features a ductile iron body and a epdm seat. Rated to up to 300°F. This model is certified lead-free for potable-water installations.
This 6 inch LFF113FP flood protection shutdown control valve protects against property damage caused by continuous discharge from a reduced pressure zone backflow assembly. With SentryPlus Alert® continuous monitoring technology in place, the flood sensor and sensor activation module attached to the assembly relief valve signal the relay box when discharge is continuous. The activation module includes a tiny time delay to prevent signaling based on intermittent or nuisance relief valve discharges. Activated through an add-on connection kit, the sensor can trigger the alert system sending notification of flood detection to facility personnel. This Classic valve style has a globe body pattern with class 150 flanged end connections.
Features
- Class 150 flanged
- SentryPlus Alert flood monitoring and alert system
- Multi-channel alert capabilities
- Solenoid control
Common Questions
- What fluid temperature can the EPDM trim handle?
- This valve is built with EPDM elastomers, good to about 300°F. Watts offers the same body with Buna-N (to 160°F), FKM/Viton (to 250°F) or EPDM (to 300°F) — pick the elastomer for your fluid temperature, not the body.
- Is this valve certified lead-free for potable water?
- Yes. The "LF" prefix denotes Watts lead-free construction, compliant with the weighted-average 0.25% lead requirement of the Safe Drinking Water Act (NSF/ANSI 372) for potable-water service.
Specifications
- Type: RPZ
- Size: 6"
- Inlet Size: 6"
- Outlet Size: 6"
- Connection: Flanged
- Body Material: Ductile Iron
- Seat / Seal Material: EPDM
- Pressure Class: Class 150
- Operation: Continuous
- Country of Origin: United States
- Warranty: 1 Year Limited
- MPN: LFF113FP 150-FP2 6
- Temperature: up to 300°F
- Certifications: NSF-61
- Lead-Free: Yes
- Item Type: Valve
- Control Function: Backflow Prevention (RPZ)
- Valve Platform: Classic (F-Series)
- Body Pattern: Globe
- End Connection / Pressure Class: 150# Flanged
- Configured Options: Flood Sensor
- Coating: Fusion-Bonded Epoxy
Product Information
Dimensions
| Size Nominal | 6" | Inlet Size | 6" |
| Outlet Size | 6" | End Connection | Flanged |
| Pressure Class | Class 150 | — | — |
Details
| Series | LFF113FP | Device Type | RPZ |
| Lead Free | Yes | Body Material | Ductile Iron |
| Seat Material | EPDM | Operation | Continuous |
| Max Temp °F | 300.0 °F | Item Type | Valve |
| Control Function | Backflow Prevention (RPZ) | Valve Platform | Classic (F-Series) |
| Body Pattern | Globe | Pressure Class End | 150# Flanged |
| Options | Flood Sensor | Coating | Fusion-Bonded Epoxy |
Certifications & Standards
| NSF-61 | — |
Compare with similar products


| Item Type | Valve
| Valve
|
| Control Function | Backflow Prevention (RPZ)
| Deluge / Fire Protection Control
|
| Valve Platform | Classic (F-Series)
| Mustang (M-Series)
|
| Body Pattern | Globe
| Globe
|
| Pressure Class End | 150# Flanged
| 150# Flanged
|
| Options | Flood Sensor
| Lead-Free Pilot, Normally Closed, Solenoid Pilot, 120VAC
|
| Coating | Fusion-Bonded Epoxy
| ArmorTek 3-Part Epoxy
|
| Series | LFF113FP
| M100D-B
|
| Country Of Origin | United States
| United States
|
| Warranty | 1 Year Limited
| 1 Year Limited
|
| Spec Sheet | ||
| Device Type | RPZ
| Globe
|
| Size Nominal | 6"
| 6"
|
| Inlet Size | 6"
| 6"
|
| Outlet Size | 6"
| 6"
|
| Lead Free | Yes | Yes |
| End Connection | Flanged
| Flanged
|
| Body Material | Ductile Iron
| Ductile Iron
|
| Seat Material | EPDM
| Buna-N
|
| Operation | Continuous
| Pilot-Operated Diaphragm
|
| Pressure Class | Class 150
| Class 150
|
| Max Temp °F | 300.0 °F | 160.0 °F |
| Certifications | NSF-61
| UL
|
