Specifications
Description
The Watts PWHSJUM40304 is a housing. It features a stainless body. Rated to 150 psi.
This 40 series commercial and industrial housing is made of 100 percent 304 stainless steel material. The convenient band clamp lid closure is standard for an easy cartridge replacement. The pipe fittings are readily accessible for easy installation. The adjustable compression cap provides superior sealing for both ends of the jumbo cartridge. The two drains are provided for clean and dirty fluids. The knife edge seals are provided at both ends of all DOE cartridges for superior performance. It is rated for temperatures up to 250 F using hi-temp cartridges and the water pressure rating up to 150 psi. The protective poly-coat over stainless steel is the standard finish.
Features
- Adjustable compression cap for superior sealing on both ends of jumbo cartridge
- 2" NPT connection
- V- Band Closure lid
- 304 stainless steel
Specifications
- Size: 2"
- Inlet Size: 2"
- Outlet Size: 2"
- Connection: Compression
- Body Material: Stainless
- Max Pressure (psi): 150
- Application: Water Treatment
- Country of Origin: United States
- Warranty: 1 Year Limited
- MPN: PWHSJUM40304
- Lead-Free: No
- System Role: Housing
Product Information
| SKU | UPC | Country of Origin | Warranty | Spec Sheet |
|---|---|---|---|---|
| 7101084 | 098268446081 | United States | 1 Year Limited | Download |
Dimensions
| Size Nominal | 2" | Inlet Size | 2" |
| Outlet Size | 2" | End Connection | Compression |
Details
| Series | PWHSJUMBO | Body Material | Stainless |
| Application | Water Treatment | Max Pressure PSI | 150.0 psi |
| System role | Housing | — | — |
Compare with similar products
| Cartridge Size | — | 20"
| 10"
| 20"
| 10"
| 10"
|
| Series | PWHSJUMBO
| PWHP HIGH TEMP
| PWHP
| PWHP
| PWHP HIGH TEMP
| PWHIB
|
| Country Of Origin | United States
| Taiwan
| United States
| China
| Taiwan
| Taiwan
|
| Warranty | 1 Year Limited
| 1 Year Limited
| 1 Year Limited
| 1 Year Limited
| 1 Year Limited
| 1 Year Limited
|
| Spec Sheet | ||||||
| Size Nominal | 2"
| 3/4"
| 1"
| 3/4"
| 3/4"
| 1"
|
| Inlet Size | 2"
| 3/4"
| 1"
| 3/4"
| 3/4"
| 1"
|
| Outlet Size | 2"
| 3/4"
| 1"
| 3/4"
| 3/4"
| 1"
|
| End Connection | Compression
| Compression
| Compression
| Compression
| Compression
| — |
| Body Material | Stainless
| Polypropylene
| Polypropylene
| Polypropylene
| Polypropylene
| — |
| Application | Water Treatment
| Water Treatment
| Water Treatment
| Water Treatment
| Water Treatment
| Water Treatment
|
| Max Pressure PSI | 150.0 psi | 100.0 psi | 100.0 psi | 100.0 psi | 100.0 psi | 100.0 psi |
| Max Temp °F | — | 100.0 °F | 100.0 °F | 100.0 °F | 100.0 °F | 100.0 °F |
| Pack Qty | — | 4
| 4
| 4
| 4
| 4
|
