Specifications
Description
The Zurn QPM43-5 is a 3/4" acudel tee -- (1) 3/4" PEX Crimp Inlet w/ (5) 1/2" PEX Crimp Outlet Ports. It features a acudel body. Rated to 160 psi.
Common Questions
- Crimp or expansion fitting -- which is this?
- This is a QickSert CR crimp/insert fitting (ASTM F2159): a polymer barb secured with a separate crimp ring or QickClamp, not a cold-expansion fitting. Use the same crimp tool and rings as the brass F1807 line -- the two material families share one crimp system.
- What standards is it listed to?
- ASTM F2159, ASTM F877, CSA-B137.5, NSF-14, NSF-61.
Specifications
- Type: QickSert Polymer Multi-Port Tee
- Size: 3/4"
- Connection: Barb
- Body Material: Acudel
- Max Pressure (psi): 160
- MPN: QPM43-5
- Certifications: ASTM F2159, ASTM F877, CSA-B137.5, NSF-14, NSF-61
- Fitting Type: Tee
- Connection System: CR-Polymer Crimp
- Port Configuration: (1) 3/4" PEX Crimp Inlet w/ (5) 1/2" PEX Crimp Outlet Ports
Product Information
| SKU | UPC | Spec Sheet |
|---|---|---|
| QPM43-5 | 084169006066 | Download |
Dimensions
| Size Nominal | 3/4" | End Connection | Barb |
Details
| Series | QPM43-5 | Device Type | QickSert Polymer Multi-Port Tee |
| Body Material | Acudel | Max Pressure PSI | 160.0 psi |
| Configuration | (1) 3/4" PEX Crimp Inlet w/ (5) 1/2" PEX Crimp Outlet Ports | Connection system | CR-Polymer Crimp |
| Fitting type | Tee | — | — |
Certifications & Standards
| ASTM F2159 | ASTM F877 |
| CSA-B137.5 | NSF-14 |
| NSF-61 | — |
Compare with similar products
| Series | QPM43-5
| QQPT443X
| QQPT434X
|
| Spec Sheet | |||
| Install Sheet | — | ||
| Device Type | QickSert Polymer Multi-Port Tee
| Qick Sert CR® Large Diameter Polymer Tee
| Qick Sert CR® Large Diameter Polymer Tee
|
| Size Nominal | 3/4"
| 3/4"
| 3/4"
|
| Lead Free | — | Yes | Yes |
| End Connection | Barb
| Barb
| Barb
|
| Body Material | Acudel
| Acetal
| Acetal
|
| Max Pressure PSI | 160.0 psi | 160.0 psi | 160.0 psi |
| Certifications | ASTM F2159, ASTM F877, CSA-B137.5, NSF-14, NSF-61
| ASTM F2159, ASTM F877, CSA-B137.5, NSF-14, NSF-61
| ASTM F2159, ASTM F877, CSA-B137.5, NSF-14, NSF-61
|
