Watts LFWAMV-W-FLXIPS 3/4X3/4 Lead-Free Angle Meter Valve, Brass, SAE Flare

The Watts LFWAMV-W-FLXIPS 3/4X3/4 is a 3/4" lead-free angle meter valve with SAE Flare connections. It features a brass body. Rated to 125 psi. This model is certified lead-free for potable-water installations.

This 3/4 x 3/4 inch lead free angle meter valve is used in light commercial and residential applications for incoming water supply service. It features a lead free cast brass body, 3/4 inch flare by 3/4 inch IPS female connections and waste feature to drain line for easy maintenance. The maximum operating pressure is 125 psi (8.6 bar).

Features

• Lead free brass body construction
• Used for incoming water supply service
• Flare by female IPS connection
• Includes waste feature for easy maintenance

Common Questions

Does it have a waste/drain port?

Yes. With the valve closed, the waste port drains or vents the downstream line — used to winterize hose bibbs, sillcocks and irrigation runs.

Is it approved for potable water?

Yes. This is a Watts LF (lead-free) model, certified to NSF/ANSI 372 for potable-water service.

Specifications

• Type: Angle Meter
• Size: 3/4"
• Inlet Size: 3/4"
• Outlet Size: 3/4"
• Connection: SAE Flare
• Body Material: Brass
• Max Pressure (psi): 125
• Application: Domestic Water
• Pack Quantity: 60
• Country of Origin: Taiwan
• Warranty: 1 Year Limited
• MPN: LFWAMV-W-FLXIPS 3/4X3/4
• Certifications: NSF/ANSI 372
• Lead-Free: Yes
• Valve Style: Angle Meter
• Pressure Rating: 125 psi WOG
• Waste / Drain Port: Yes
• Replacement Part: No
