Watts LFM1115-3 2 Lead-Free Check Valve, Ductile Iron, NPT

The Watts LFM1115-3 2 is a 2" lead-free angle-pattern pilot-operated pressure reducing & check control valve with NPT connections. It features a ductile iron body. This model is certified lead-free for potable-water installations.

This 2 inch angle pattern NPT threaded epoxy coated pressure reducing control valve, model LFM1115-3, is designed to automatically reduce a fluctuating higher inlet pressure to a constant lower downstream pressure regardless of varying flow rates. The quick closing action of the valve limits possible damaging high inlet pressure from passing through the valve to downstream piping. Piloted with a check feature to close the valve when downstream pressure becomes greater than upstream pressure. This valve has a fixed orifice closing speed and isolation cocks.

Features

• Angle pattern
• NPT threaded
• Epoxy coated
• Copper tubing/brass fittings

Common Questions

Is this valve certified lead-free for potable water?

Yes. The "LF" prefix denotes Watts lead-free construction, compliant with the weighted-average 0.25% lead requirement of the Safe Drinking Water Act (NSF/ANSI 372) for potable-water service.

Specifications

• Type: Check
• Size: 2"
• Inlet Size: 2"
• Outlet Size: 2"
• Connection: NPT
• Body Material: Ductile Iron
• Operation: Pilot-Operated Diaphragm
• Country of Origin: United States
• Warranty: 1 Year Limited
• MPN: LFM1115-3 2
• Lead-Free: Yes
• Item Type: Valve
• Control Function: Pressure Reducing & Check
• Valve Platform: Mustang (M-Series)
• Body Pattern: Angle
• End Connection / Pressure Class: THD (NPT Threaded)
• Coating: Fusion-Bonded Epoxy
