Watts LFDPTG3-3-0-200 1/2 Lead-Free Pressure/Temperature Gauge, Steel, NPT

The Watts LFDPTG3-3-0-200 1/2 is a 1/2" lead-free pressure/temperature gauge reading 0-200 psi. It features a steel body. Rated to 60°F to 320°F. This model is certified lead-free for potable-water installations.

This 1/2 inch lead free combination pressure and temperature gauge is used in commercial, residential, and institutional HVAC applications. It features a center, back-entry, black enamel steel case, Kostil Polymer window, 1/2 inch NPT connection, copper alloy Bourdon tube pressure element, and bimetal spiral spring. Accuracy is ASME, Type B. This gauge features a 3 inch dial with pressure rating scale from 0 to 200 psi and temperature range 60 to 320 degrees F.

Features

• ABS polymer case
• Kostil polymer window
• Copper alloy Bourdon sensing element
• 1/2" (15 MM) NPT connection

Common Questions

What is the indicating range?

The dial reads 0-200 psi. Size the range to your working pressure — an oversized dial reads too coarse to be useful.

Specifications

• Size: 1/2"
• Connection: NPT
• Body Material: Steel
• Application: General Service
• Pack Quantity: 40
• Country of Origin: BG
• Warranty: 1 Year Limited
• MPN: LFDPTG3-3-0-200 1/2
• Temperature: 60°F to 320°F
• Certifications: ASME B40.100
• Lead-Free: Yes
• Type: Pressure/Temperature Gauge
• Gauge Range: 0-200 psi
• Dial Size: 3"
