The Watts LFDNRS-RW-GATE 2 1/2 is a lead-free replacement shutoff gate for a 2-1/2" domestic NRS resilient wedge gate valve — the gate assembly only, not a complete valve. It features a rubber seat. This model is certified lead-free for potable-water installations.
This replacement shutoff is designed for a 2 1/2 inch domestic non-rising stem (NRS) resilient wedge gate valve. This lead free shutoff valve includes a 1/2 inch ball valve.
Features
- For replacement or repair in field
- For domestic NRS resilient wedge gate valve
- Includes a 1/2 inch ball valve
- Fits 2 1/2 inch valve
Common Questions
- Is this a complete valve or just the replacement gate?
- Just the gate. The LFDNRS-RW-GATE 2 1/2 is the replacement shutoff gate assembly for a 2-1/2" domestic NRS resilient wedge gate valve — it does not include the body, bonnet or handwheel. If the valve body itself is damaged, order a complete gate valve instead.
- Does it include test cocks?
- No. This is the plain gate, without test cocks. If the shutoff you are servicing is tapped for test cocks, order the matching -TC version.
- Rising or non-rising stem?
- This gate fits a non-rising-stem (NRS) valve. The stem does not travel as the valve opens — order the OS&Y gate for an outside-stem-and-yoke valve.
- Is this UL/FM listed for fire service?
- No. Replacement gates are not themselves UL/FM listed. Servicing a listed fire-service valve with a replacement component can affect its listing — confirm with the authority having jurisdiction before you install it.
Specifications
-
Type: Gate
-
Size: 2-1/2"
-
Inlet Size: 2-1/2"
-
Outlet Size: 2-1/2"
-
Seat / Seal Material: Rubber
-
Application: Domestic Water
-
Shutoff: NRS Gate
-
Country of Origin: United States
-
Warranty: 1 Year Limited
-
MPN: LFDNRS-RW-GATE 2 1/2
-
Certifications: ANSI-A112.1.2, NSF/ANSI 372
-
Lead-Free: Yes
-
Valve Style: Replacement Gate
-
Stem Type: Non-Rising (NRS)
-
Wedge / Disc Type: Resilient
-
UL/FM Listed: No
-
Replacement Part: Yes
-
Fits Valve: 2-1/2" domestic NRS resilient wedge gate valve
-
Test Cocks: No
