Watts LF17 1 Lead-Free Strainer, Bronze, FNPT

The Watts LF17 1 is a 1" lead-free inline union-pattern strainer with FNPT connections that removes pipeline debris and particulates to protect downstream equipment. It ships with a 40 mesh 304 stainless steel screen. It features a bronze body and a buna-n seat. Rated to 250 psi. This model is certified lead-free for potable-water installations.

This 1 inch lead free in-line single union strainer is designed to protect system components from dirt, rust and other damaging debris in the piping system. Is ideal for quick removal from equipment for cleaning or where feed line separation is required. It features a lead free bronze body with union end and NPT threaded female connections, 40 mesh stainless steel screen and Buna-N union seal. The maximum working pressure is 250 psi (17.2 bar) WOG at 180 degrees F (82 degrees C).

Features

• Maximum working pressure 250 psi at 180 degrees F
• NPT threaded female connections
• 40 mesh stainless steel screen
• Buna-N union seal
• Includes: Strainer

Common Questions

What mesh or screen size does it come with?

LF17 1 ships with a 40 mesh 304 Stainless Steel screen (40 openings per linear inch). That is the standard screen Watts supplies for this body at this pipe size -- the screen size is not called out in the model number, so it varies by size across the series.

Does it have a blowoff / blowdown port?

No. This model has a solid retainer cap, so cleaning means removing the cap and lifting out the screen. If you want to blow the strainer down in place, order the tapped-cap version of this body instead.

What is the "seat material" on a strainer?

A strainer has no seat -- nothing closes against anything. The Buna-N called out here is the retainer-cap seal (the gasket between the cap and the body), which is what limits the temperature and chemical compatibility of the closure.

Specifications

• Type: Strainer
• Size: 1"
• Connection: FNPT
• Body Material: Bronze
• Cap Seal / Gasket Material: Buna-N
• Max Pressure (WOG, psi): 250
• Application: Domestic Water
• Pack Quantity: 12
• Country of Origin: United States
• Warranty: 1 Year Limited
• MPN: LF17 1
• Certifications: NSF-372
• Lead-Free: Yes
• Strainer Pattern: Inline Union
• Screen Type: Mesh
• Screen Mesh: 40
• Screen Material: 304 Stainless Steel
• Blowoff / Drain Tapping: No
• Blowoff Plug Included: No
• Body Coating: None
