Watts F1116 8 Lead-Free Relief Valve, Bronze, Flanged

The Watts F1116 8 is a 8" lead-free angle-pattern pilot-operated pressure relief / sustaining / backpressure control valve with Flanged connections. It features a bronze body and a buna-n seat. Rated to up to 160°F. This model is certified lead-free for potable-water installations.

This 8 inch angle pattern single chamber relief valve, series 1116FM, meets all requirements for UL listed, FM approved fire protection service. The design and features incorporated in the Watts ACV valve assures accurate control, dependable performance, and long life. Automatically maintains a constant pressure in the fire protection system by relieving excess pressure.

Features

• Angle Pattern
• Class 300 x Class 150 Flanged
• Epoxy coated
• Copper tubing/brass fittings

Common Questions

What fluid temperature can the Buna-N trim handle?

This valve is built with Buna-N elastomers, good to about 160°F. Watts offers the same body with Buna-N (to 160°F), FKM/Viton (to 250°F) or EPDM (to 300°F) — pick the elastomer for your fluid temperature, not the body.

Is this valve UL Listed and FM Approved for fire protection?

Yes — this model carries the UL listing and FM approval required for fire-protection service. Non-listed control valves cannot be substituted on a fire job even when the body and pilot are otherwise identical.

Specifications

• Type: Relief
• Size: 8"
• Inlet Size: 8"
• Outlet Size: 8"
• Connection: Flanged
• Body Material: Bronze
• Seat / Seal Material: Buna-N
• Pressure Class: Class 300
• Application: Fire Protection
• Operation: Pilot-Operated Diaphragm
• Country of Origin: United States
• Warranty: 1 Year Limited
• MPN: F1116 8
• Temperature: up to 160°F
• Certifications: UL, FM
• Lead-Free: Yes
• Item Type: Valve
• Control Function: Pressure Relief / Sustaining / Backpressure
• Valve Platform: Classic (F-Series)
• Body Pattern: Angle
• End Connection / Pressure Class: 300# Flanged
• Coating: Fusion-Bonded Epoxy
• UL Listed / FM Approved: Yes
