Watts BD5 1/2 3/4", Brass, Sweat

The Watts BD5 1/2 is a 3/4" brass hydronic heating component. It features a brass body. Rated to 200 psi and up to 250°F.

This 1/2 inch straight pattern brass boiler drain shutoff is designed for water service use in commercial and residential hydronic heating systems. It provides positive shutoff for boiler drain or sill cock applications. This shutoff consists of a brass body construction and 1/2 inch dual connection for either solder or male IPS and 3/4 inch hose thread connection, PTFE stem packing, and cast iron handwheel. The maximum pressure is 200 psi (14 bar) WOG and maximum temperature is 250 degrees F (121 degrees C).

Features

• Brass body
• Straight pattern
• Dual inlet connection
• Hose thread outlet

Common Questions

What is it designed for?

It is intended for hydronic heating service.

Specifications

• Size: 3/4"
• Inlet Size: 1/2"
• Outlet Size: 3/4"
• Connection: Sweat
• Body Material: Brass
• Max Pressure (psi): 200
• Application: Hydronic Heating
• Pack Quantity: 144
• Country of Origin: China
• Warranty: 1 Year Limited
• MPN: BD5 1/2
• Temperature: up to 250°F
• Lead-Free: No
