The Watts 415-015 1 1/4 is a 1-1/2" pressure relief valve for low-pressure steam boiler service, factory set at 15 psi. It features a bronze body. Rated to 15 psi.
This 1 1/4 inch dependable, low cost, high capacity safety relief valve is designed for pressure cookers and steam cleaning equipment requirements used in low pressure applications. It features a bronze body, stainless steel spring, top guided stem, NPT threaded male inlet by threaded female outlet (drain) connection and a non-stick PTFE disc-to-metal seat to assure positive shutoff. The factory pressure setting for saturated steam service is set at 15 psi.
Features
- Pressure for saturated steam service set at 15 psi
- Bronze body
- Male NPT screwed inlet and female NPT screwed outlet
- Top guided stem and non-stick PTFE disc to metal seat assures positive shutoff
- ASME, section IV rating
- Used for industrial and commercial low pressure applications
- High capacity
- Seat located above drain
- Stainless steel spring
Common Questions
- What pressure is this valve set to?
- It is factory set to relieve at 15 psi. The setting is fixed and is not field-adjustable.
- Is this ASME rated?
- Yes — it carries an ASME Section IV rating for low-pressure steam heating boilers and is National Board certified. It is a steam safety valve; do not substitute it for a hot-water ("HV") relief valve, and do not use it above its set pressure.
- Can I use this on potable water?
- No. This is a boiler valve and is not approved for potable water, and that is true regardless of what the lead-free column says — hydronic boiler water is a closed, treated loop and is not drinking water. For a potable hot water heater or storage tank, use a T&P relief valve listed to ANSI Z21.22 / CSA 4.4 instead.
Specifications
-
Type: Relief
-
Size: 1-1/2"
-
Inlet Size: 1-1/4"
-
Outlet Size: 1-1/2"
-
Connection: FNPT
-
Body Material: Bronze
-
Max Pressure (psi): 15
-
Pack Quantity: 6
-
Country of Origin: United States
-
Warranty: 1 Year Limited
-
MPN: 415-015 1 1/4
-
Certifications: ASME Section IV, NBBI
-
Lead-Free: No
-
Relief Type: Pressure Only
-
Factory Set Pressure (psi): 15
-
ASME Code Rating: ASME Section IV (Steam)
-
Application: Low-Pressure Steam Boiler
-
Connection Configuration: MNPT inlet x FNPT outlet
-
Approved for Potable Water: No
-
SentryPlus Alert Flood Sensor: No
