Watts 220P1 Float Valve, Glass-Reinforced Nylon, Barb

The Watts 220P1 is a 1" piston-operated trough float valve for livestock watering and agricultural water supply, serviceable in place. It features a glass-reinforced nylon body and a buna-n seat. Rated to 200 psi.

This 1 inch float valve is piston operated and has removable seats giving it flow variability. The valve is serviceable and comes with a barbed outlet to fit a silencer tube for cistern applications.

Features

• Can be submerged to monitor and control water levels in small or medium-sized full-flow troughs while reducing risk of damage from livestock
• Removable seats allow for variable pressure applications
• Features full flow rates of 3-15gpm
• Construction of UV-stable fiberglass-reinforced nylon, Acetyl (POM) and brass ensures durability and resistance to both corrosion and dezincification
• Ideal for use in livestock watering, agricultural water supply, ranch, farm and/or hobby farm settings

Common Questions

Can I use it on drinking water?

No. This valve is not certified lead-free and is for non-potable service only — cooling tower and refrigeration make-up, irrigation, livestock watering and tank fill. Do not install it on a potable water supply.

What is the flow capacity?

3-15 GPM. Size the valve to how fast the tank or trough has to refill, not just to the pipe it lands on.

Specifications

• Type: Float
• Size: 1"
• Connection: Barb
• Body Material: Glass-Reinforced Nylon
• Seat / Seal Material: Buna-N
• Max Pressure (psi): 200
• Application: Livestock
• Pack Quantity: 120
• Country of Origin: NZ
• Warranty: 1 Year Limited
• MPN: 220P1
• Lead-Free: No
• Actuation: Piston
• Mounting: Submerged
• Max Flow (GPM): 15.0
• Flow Capacity: 3-15 GPM
