Specifications
Description
The Watts 4 FP-SK-77F-FDA-OSY is a 4" wye-pattern strainer with Flanged connections that removes pipeline debris and particulates to protect downstream equipment. It ships with a 1/16" perforated 304 stainless steel screen. It features a cast iron body. Rated to 200 psi.
This 4 inch cast iron flanged wye pattern strainer has 304 stainless steel perforated screens, a cast iron flanged retainer cap and a drain blow off connection furnished with a closure plug. The strainer also features a double coated, heat fused epoxy coating on the interior and exterior for FDA approved sanitary applications. It is supplied with an upstream OSY shutoff.
Features
- Wye pattern
- Cast iron body
- 304 stainless steel perforated screens
- Flanged
- Includes: Strainer
Common Questions
- What mesh or screen size does it come with?
- 4 FP-SK-77F-FDA-OSY ships with a 1/16" perforated 304 Stainless Steel screen. That is the standard screen Watts supplies for this body at this pipe size -- the screen size is not called out in the model number, so it varies by size across the series.
- Can I use this on steam?
- Yes. 4 FP-SK-77F-FDA-OSY is rated 125 psi WSP on steam, which is a separate and much lower limit than its 200 psi WOG (cold water, oil, gas) rating. Do not size steam service off the WOG number.
- Does it have a blowoff / blowdown port?
- Yes. The retainer cap/cover is tapped for a blowoff connection, so you can flush accumulated debris by pulling the plug or piping a blowdown valve to it -- no need to break the strainer apart. The closure plug is included.
Specifications
- Type: Strainer
- Size: 4"
- Connection: Flanged
- Body Material: Cast Iron
- Pressure Class: Class 125
- Max Pressure (WOG, psi): 200
- Country of Origin: United States
- Warranty: 1 Year Limited
- MPN: 4 FP-SK-77F-FDA-OSY
- Lead-Free: No
- Strainer Pattern: Wye
- Screen Type: Perforated
- Screen Perforation: 1/16"
- Screen Material: 304 Stainless Steel
- Blowoff / Drain Tapping: Yes
- Blowoff Plug Included: Yes
- Max Steam Pressure (WSP, psi): 125
- Body Coating: FDA Epoxy
Product Information
Dimensions
| Size Nominal | 4" | End Connection | Flanged |
| Pressure Class | Class 125 | — | — |
Details
| Series | 77F-DI-FDA-125 | Device Type | Strainer |
| Body Material | Cast Iron | Max Pressure PSI | 200.0 psi |
| Options | Strainer | Pattern | Wye |
| Screen Type | Perforated | Perforation Size | 1/16" |
| Screen Material | 304 Stainless Steel | Blowoff Tapped | Yes |
| Blowoff Plug Included | Yes | Max Steam Pressure PSI | 125.0 psi |
| Body Coating | FDA Epoxy | — | — |
Compare with similar products
| Pattern | Wye
| Wye (45°)
| Wye (45°)
|
| Screen Type | Perforated
| Mesh
| Mesh
|
| Mesh Size | — | 100
| 20
|
| Screen Material | 304 Stainless Steel
| 304 Stainless Steel
| 304 Stainless Steel
|
| Blowoff Tapped | Yes | Yes | Yes |
| Blowoff Plug Included | Yes | Yes | Yes |
| Body Coating | FDA Epoxy
| None
| None
|
| Screen Options Available | — | Yes | Yes |
| Series | 77F-DI-FDA-125
| P777
| P777
|
| Country Of Origin | United States
| Mexico
| Mexico
|
| Warranty | 1 Year Limited
| 1 Year Limited
| 1 Year Limited
|
| Spec Sheet | |||
| Install Sheet | |||
| Device Type | Strainer
| Strainer
| Strainer
|
| Size Nominal | 4"
| 3/8"
| 3/8"
|
| End Connection | Flanged
| NPT
| NPT
|
| Body Material | Cast Iron
| Thermoplastic
| Thermoplastic
|
| Seat Material | — | Buna-N
| Buna-N
|
| Application | — | Domestic Water
| Domestic Water
|
| Max Pressure PSI | 200.0 psi | 300.0 psi | 300.0 psi |
| Pack Qty | — | 50
| 50
|
| Options | Strainer
| Strainer
| Strainer
|
