Specifications
Description
The Viega 87850 is a 3/4" zero-lead ball valve from Viega's ProPress system with Press x Press ends for copper tube (CTS sizes). It features a silicium bronze, brass body. Rated to 0°F to 250°F. This model is certified lead-free for potable-water installations.
Features
- Smart Connect Technology, Zero Lead
- For potable water installations
- Not suitable for fuel gas application
- brass body, silicon bronze press ends
- Press connection
- Full port, with drain port
- Components EPDM sealing elements, non-lockable metal handle, stainless steel ball
Common Questions
- What pipe and press tool does this valve need?
- It installs with a ProPress press jaw or ring, on copper tube (CTS sizes).
- Which sealing element is in the press ends?
- The press connections seal with EPDM sealing elements, which Viega rates from 0°F to 250°F.
- Is this valve lead-free?
- Yes. Viega marks this model Zero Lead.
Specifications
- Type: Ball Valve
- Size: 3/4"
- Connection: Press
- Body Material: Silicium bronze, brass
- Application: Domestic Water
- Country of Origin: China
- MPN: 87850
- Temperature: 0°F to 250°F
- Lead-Free: Yes
- Press Profile: ProPress
- Size Basis: CTS
- Sealing Element: EPDM
- For Use On: Copper
- End Connections: Press x Press
- Ball Material: Stainless Steel
- Port Style: Full
Product Information
| SKU | Country of Origin |
|---|---|
| 87850 | China |
Dimensions
| Size Nominal | 3/4" | End Connection | Press |
Details
| Series | ProPress | Device Type | Ball Valve |
| Lead Free | Yes | Body Material | Silicium bronze, brass |
| Application | Domestic Water | Port Style | Full |
| Max Temp °F | 250.0 °F | Min Temp °F | 0.0 °F |
| Ball Material | Stainless Steel | Work material | Copper |
| End combination | Press x Press | — | — |
Compare with similar products
| Port Style | Full
| Full
| Full
| Full
| Full
| Full
|
| Ball Material | Stainless Steel
| Stainless Steel
| Stainless Steel
| Stainless Steel
| Stainless Steel
| Stainless Steel
|
| Series | ProPress
| ProPress
| ProPress
| ProPress
| ProPress
| ProPress
|
| Country Of Origin | China
| China
| China
| Germany
| Germany
| China
|
| Device Type | Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
|
| Size Nominal | 3/4"
| 2"
| 1-1/2"
| 2"
| 1-1/2"
| 1-1/4"
|
| Lead Free | Yes | Yes | Yes | Yes | Yes | Yes |
| End Connection | Press
| — | — | Press
| Press
| — |
| Body Material | Silicium bronze, brass
| Silicium bronze
| Silicium bronze
| Silicium bronze
| Silicium bronze
| Silicium bronze
|
| Application | Domestic Water
| Domestic Water
| Domestic Water
| Domestic Water
| Domestic Water
| Domestic Water
|
| Max Temp °F | 250.0 °F | — | — | 250.0 °F | 250.0 °F | — |
| Min Temp °F | 0.0 °F | — | — | 0.0 °F | 0.0 °F | — |
