Specifications
Description
The Viega 87205 is a 3/4" swing check valve from Viega's MegaPress FKM system with Press x Press ends for steel pipe (IPS sizes). It features a brass body. Rated to 14°F to 284°F.
Features
- Smart Connect Technology
- For use with Sch. 5 to Sch. 40 carbon steel pipe
- Not suitable for potable water installations, fuel gas application
- brass body, carbon steel press ends
- Press connection
- Components PTFE disc seal
Common Questions
- What pipe and press tool does this valve need?
- It installs with a MegaPress press jaw or ring, on steel pipe (IPS sizes).
- Which sealing element is in the press ends?
- The press connections seal with FKM sealing elements, which Viega rates from 14°F to 284°F.
Specifications
- Type: Check Valve
- Size: 3/4"
- Connection: Press
- Body Material: Brass
- Application: Non-Potable Water
- Country of Origin: Italy
- MPN: 87205
- Temperature: 14°F to 284°F
- Press Profile: MegaPress
- Size Basis: IPS
- Sealing Element: FKM
- For Use On: Steel
- End Connections: Press x Press
- Check Mechanism: Swing
Product Information
| SKU | Country of Origin |
|---|---|
| 87205 | Italy |
Dimensions
| Size Nominal | 3/4" | End Connection | Press |
Details
| Series | MegaPress FKM | Device Type | Check Valve |
| Body Material | Brass | Application | Non-Potable Water |
| Max Temp °F | 284.0 °F | Min Temp °F | 14.0 °F |
| Check Mechanism | Swing | Work material | Steel |
| End combination | Press x Press | — | — |
