Similar products
Specifications
Description
The Viega 24015 is a 1-1/4" ball valve from Viega's ProPress system with Press x Press ends for copper tube (CTS sizes). It features a bronze, brass body. Rated to 0°F to 250°F.
Features
- Smart Connect Technology
- For non-potable application
- brass body, silicon bronze press ends
- Press connection
- Full port
- Components EPDM sealing elements, non-lockable metal handle
Common Questions
- What pipe and press tool does this valve need?
- It installs with a ProPress press jaw or ring, on copper tube (CTS sizes).
- Which sealing element is in the press ends?
- The press connections seal with EPDM sealing elements, which Viega rates from 0°F to 250°F.
Specifications
- Type: Ball Valve
- Size: 1-1/4"
- Connection: Press
- Body Material: Bronze, brass
- Application: Non-Potable Water
- Country of Origin: Italy
- MPN: 24015
- Temperature: 0°F to 250°F
- Press Profile: ProPress
- Size Basis: CTS
- Sealing Element: EPDM
- For Use On: Copper
- End Connections: Press x Press
- Port Style: Full
Product Information
| SKU | Country of Origin |
|---|---|
| 24015 | Italy |
Dimensions
| Size Nominal | 1-1/4" | End Connection | Press |
Details
| Series | ProPress | Device Type | Ball Valve |
| Body Material | Bronze, brass | Application | Non-Potable Water |
| Port Style | Full | Max Temp °F | 250.0 °F |
| Min Temp °F | 0.0 °F | Work material | Copper |
| End combination | Press x Press | — | — |
Compare with similar products
| Port Style | Full
| Full
| Full
| Full
| Full
| Full
|
| Ball Material | — | Stainless Steel
| Stainless Steel
| — | — | Stainless Steel
|
| Series | ProPress
| ProPress
| ProPress
| ProPress
| ProPress
| ProPress
|
| Country Of Origin | Italy
| Germany
| Germany
| Italy
| Italy
| Germany
|
| Device Type | Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
| Ball Valve
|
| Size Nominal | 1-1/4"
| 3/4"
| 1/2"
| 1/2"
| 3/4"
| 1"
|
| Lead Free | — | Yes | Yes | — | — | Yes |
| End Connection | Press
| Press
| Press
| Press
| Press
| Press
|
| Body Material | Bronze, brass
| Silicium bronze
| Silicium bronze
| Bronze, brass
| Bronze, brass
| Silicium bronze
|
| Application | Non-Potable Water
| Domestic Water
| Domestic Water
| Non-Potable Water
| Non-Potable Water
| Domestic Water
|
| Max Temp °F | 250.0 °F | 250.0 °F | 250.0 °F | 250.0 °F | 250.0 °F | 250.0 °F |
| Min Temp °F | 0.0 °F | 0.0 °F | 0.0 °F | 0.0 °F | 0.0 °F | 0.0 °F |
