Specifications
Description
The Viega ProPress tee (model 0918XL, order code 20749) has a 3" Press x 2-1/2" Press x 2-1/2" Press port configuration and is made for use with ASTM B88 and B75 tubing. It features a copper body. Rated to 0°F to 250°F.
Features
- Smart Connect Technology
- For use with ASTM B88 and B75 tubing
- Copper
- Press connection
- Components EPDM sealing elements
Common Questions
- Which pipe does this fitting fit?
- This ProPress fitting is made for use with ASTM B88 and B75 tubing. It is CTS sized: an IPS pipe of the same nominal size has a different outside diameter and will not seal in it.
- Which press tool and jaw do I need?
- Press it with jaws or rings made for the ProPress XL-C profile. XL sizes (2-1/2" to 4") use the XL ring system rather than the standard jaws. A jaw made for a different profile will not make a warrantable joint.
- What temperature and pressure is it rated for?
- It seals with a factory-installed EPDM sealing element, rated 0°F to 250°F (Viega seals and gaskets data). Viega's application chart rates this system to 300 psi.
- Can it be used on drinking water?
- Yes. Viega's application chart lists ProPress with the EPDM sealing element for potable water.
- How do I find a joint that was not pressed?
- Smart Connect technology: an unpressed connection leaks during a low-pressure test, so a missed press is found before the system goes into service.
Specifications
- Size (Run): 3"
- Connection: Press
- Body Material: Copper
- Application: Domestic Water
- Country of Origin: Germany
- MPN: 20749
- Temperature: 0°F to 250°F
- Fitting Type: Tee
- Port Configuration: 3" Press x 2-1/2" Press x 2-1/2" Press
- End Connections: Press x Press x Press
- Size Basis (CTS / IPS): CTS
- Sealing Element: EPDM
- Press Profile: ProPress XL-C
- For Use On: Copper
- Max Operating Pressure (psi): 300
Product Information
| SKU | Country of Origin |
|---|---|
| 20749 | Germany |
Dimensions
| Size Nominal | 3" | End Connection | Press |
Details
| Series | ProPress | Body Material | Copper |
| Application | Domestic Water | Max Temp °F | 250.0 °F |
| Min Temp °F | 0.0 °F | Operating pressure max psi | 300.0 PSI |
| Work material | Copper | Configuration | 3" Press x 2-1/2" Press x 2-1/2" Press |
| End combination | Press x Press x Press | Fitting type | Tee |
