Specifications
Description
Uponor AquaPEX White is 1-1/4" CTS PEX-a tubing (SDR 9), sold as a bundle of 5 straight 20 ft sticks, 100 ft total, 1.375" OD x 1.054" ID. Use Uponor AquaPEX® white straight-length pipe in domestic hot, cold, and hot-water recirculation systems as well as AquaSAFE™ residential fire safety systems. The pipe is available in sizes from ½" to 3" in 20-foot lengths. It is also suitable for use in hydronic heating and/or cooling applications where the system contains no ferrous corrodible components or where any ferrous components are isolated from the pipe. It features a PEX body. Rated to up to 200°F.
Common Questions
- Is it approved for drinking water?
- Yes. Uponor lists it to NSF/ANSI/CAN 61 with a potable-water (pw) listing.
- What pressure and temperature is it rated for?
- Uponor rates it at 160 psi @ 73°F, 100 psi @ 180°F, 80 psi @ 200°F.
- Is the price per stick or per bundle?
- Per bundle of 5 sticks.
Specifications
- Size: 1-1/4"
- Body Material: PEX
- Application: Domestic Water
- Pack Quantity: 5
- MPN: F1921250
- Temperature: up to 200°F
- Certifications: ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, UL-1821, ASTM F876, ASTM F877
- Product Role: Straight Length
- Color: White
- Length: 20 ft
- Sold By: Bundle
- Max Working Pressure (PSI): 160
- Pressure / Temperature Rating: 160 psi @ 73°F, 100 psi @ 180°F, 80 psi @ 200°F
Product Information
| SKU | UPC | Spec Sheet |
|---|---|---|
| F1921250 | 673372115827 | Download |
Dimensions
| Size Nominal | 1-1/4" | — | — |
Details
| Series | AquaPEX | Body Material | PEX |
| Application | Domestic Water | Max Temp °F | 200.0 °F |
| Pack Qty | 5 | Length | 240.0 in |
| Max temp f note | 160 psi @ 73°F, 100 psi @ 180°F, 80 psi @ 200°F | Operating pressure max psi | 160.0 PSI |
| Uom | Bundle | — | — |
Certifications & Standards
| ASTM F1960 | ASTM F2023 |
| CSA-B214 | CSA-B137.5 |
| NSF-14 | NSF-61 |
| UL-1821 | ASTM F876 |
| ASTM F877 | — |
Compare with similar products
| Series | AquaPEX
| AquaPEX
| AquaPEX
| AquaPEX
| AquaPEX
|
| Spec Sheet | |||||
| Size Nominal | 1-1/4"
| 2"
| 3/4"
| 1/2"
| 1"
|
| Body Material | PEX
| PEX
| PEX
| PEX
| PEX
|
| Application | Domestic Water
| Domestic Water
| Domestic Water
| Domestic Water
| Domestic Water
|
| Max Temp °F | 200.0 °F | 200.0 °F | 200.0 °F | 200.0 °F | 200.0 °F |
| Certifications | ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, UL-1821, ASTM F876, ASTM F877
| ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, ASTM F876, ASTM F877
| ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, UL-1821, ASTM F876, ASTM F877
| ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, ASTM F876, ASTM F877
| ASTM F1960, ASTM F2023, CSA-B214, CSA-B137.5, NSF-14, NSF-61, UL-1821, ASTM F876, ASTM F877
|
| Pack Qty | 5
| 5
| 15
| 25
| 10
|
