The TOTO TES100AA#CP is a single-spout, sensor-operated liquid soap dispenser with a solid brass spout and body and a removable 0.4 gal (1,500 ml) soap tank, powered by 4 D batteries.
TOTO's new AC or DC powered soap dispensers are approved by the FDA when used with TOTO TSFB1 soap.
Features
- Single Spout
- Sensor operated liquid soap dispenser
- Solid Brass Spout and Body
- AC Power Option
- Warranty Requires use of TOTO Soap (Sold Separately)
- ADA Compliant
- Recommended to use with TOTO Soap
Common Questions
- What size hole does it need?
- The base covers a 1 to 1-1/4 in hole; with the optional THP3140#CP escutcheon it covers 1-1/4 to 1-1/2 in.
- Which soap does it use?
- TOTO soap is required: using any other soap voids the three-year warranty. TOTO lists TSF201 (four 1-gallon bottles, Green Seal GS-41), TSF205 (5-gallon pail) and TSFG1 (antibacterial, four 1-gallon bottles).
Specifications
-
Warranty: 3 Years (requires TOTO soap)
-
MPN: TES100AA#CP
-
Product Role: Complete Dispenser
-
Number of Spouts: 1
-
Kit Includes: Spout and Body;Removable 0.4 gal (1,500 ml) Soap Tank;AC Adapter
-
Power Source: AC (Plug-In)
-
Mount Type: Deck-Mount
-
Finish: Polished Chrome
TOTO Spec Sheet Data
-
Power Supply: 4 x D 1.5 V alkaline batteries
-
Soap Type: Liquid
-
Tank Capacity: 0.4 gal (1,500 ml)
-
Dispense Volume: 0.03 oz (1.0 ml)
-
Sensor Range: 5-7/8 in
From TOTO spec sheet SS-01095.
