Spartan Tool IRIS HD Mainline Camera Crawler System 64700000

The Spartan Tool IRIS HD Mainline Camera Crawler System is a push-rod video inspection camera for 6" to 48" lines.

Mainline sewer inspection system for pipeline maintenance and damage detection. The IRIS HD by Insight Vision is an Integrated Remote Inspection System equipped with a 3-megapixel digital HD color camera. It includes motion posture sensors, an intelligent control terminal, high-powered LED lighting, and automatic cable management. Delivering real-time imaging and video recording for your inspection needs from sewer to storm water applications. This system supports on-site inspection reports for project evaluation, acceptance, maintenance, and repair options. Features Handles 6-to-48-inch pipe diameters across various pipe materials Dual 91W brushless DC motors, 35-degree climbing, continuously variable speed up to 108 feet/minute 3MP digital HD camera with 360-degree axial rotation, 270-degree tilt, autofocus, and 160x zoom (10x optical, 16x digital); and 2MP rear camera Adjustable high-intensity LEDs Samsung Galaxy Tab S10 Ultra tablet interface (wired/wireless), touchscreen, Bluetooth controller Tablet comes with app for full inspection control: live preview, video recording, defect grading, cable length, lift height, crawler speed, GPS location identification, preloaded damage catalog, inclination Up to 12-inch camera center height Multiple wheel sizes Aviation-grade twist-lock cable connectors One-button camera scan, automated cable rewind, directional/adaptive cruise mode 512 Hz Sonde Portable, easy transport reel with four wheels and handle Safety IP68 waterproof crawler body Real-time monitoring of air pressure and tilt Rollover protection Emergency Stop

Common Questions

What pipe sizes does this camera work in?

This system is built for 6" to 48" lines, per Spartan Tool's own specifications.

Can a locator find this camera head underground?

Yes -- it carries a built-in 512 Hz sonde that a compatible locator or transmitter can trace from the surface.

Specifications

• Type: Inspection Camera
• Warranty: 2 years (Spartan Tool equipment warranty)
• MPN: 64700000
• Pipe Size Range: 6" to 48"
• Display: Tablet included (Samsung Galaxy Tab S10 Ultra)
• Video Resolution: 3 MP
• Sonde Frequency (Hz): 512
• Waterproof Rating: IP68

Technical Data: IRIS HD

• Pipe range: 6 inch to 48 inch
• Drive speed: 108 feet/min
• Drive motors: Dual 91W brushless DC motors
• Climbing angle: 35° climbing
• Camera resolution: 3MP digital HD camera
• Camera zoom: 160x zoom (10x optical, 16x digital)
• Camera rotation and tilt: 360° axial rotation, 270° tilt
• Rear camera: 2MP rear camera
• Camera lift: Up to 12 inch camera center height
• Control station: Samsung Galaxy Tab S10 Ultra
• Locator: 512Hz sonde
• Waterproof rating: IP68 waterproof crawler body
• Wheel options: five size options

From Spartan Tool's own documentation (InsightVision Brochure IRISHD).
