Description
The Sloan ROYAL 997-1.0-RB is a manual diaphragm-type flush valve for a urinal. It delivers 1.0 gallons per flush, with a top spud connection at a concealed body. It features a semi-red brass body and a permex synthetic rubber diaphragm seat.
Concealed urinal flushometer with remotely positioned push-button actuators, ADA compliant, and ASSE 1037 rated.
Options on this configuration: 2"-10-3/4" L Dimension (LDIM). Sloan model number: ROYAL 997-1.0-RB.
Features
- 1.0 gpf, Rough Brass Finish, Fixture Connection Top Spud, Single Flush, 2"-10.75" L Dimension
- Various types of push-button flush actuators, which can be remotely positioned
- Flush volumes start as low as 1.0 gpf/3.8 Lpf
- Water conservation is aided by the ADA-compliant, non-hold-open actuator, Vandal-resistant stop cap to facilitate security
- Made from rough brass
- PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
- Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
- Valve shall be in compliance to the applicable sections of ASSE 1037
Common Questions
- What fixture and flush volume is this valve for?
- Per Sloan's own spec, it serves a urinal, 1.0 gallons per flush, a top spud connection.
- Is this exposed or concealed, and does it need a wall box?
- Concealed -- the body sits behind the wall, with only the cover or trim visible.
- Is this ADA, WaterSense, or ASSE 1037 listed?
- Yes -- Sloan lists it as ADA and ASSE-1037.
Specifications
- Type: Flushometer
- Inlet Size: 3/4"
- Body Material: Semi-Red Brass
- Diaphragm Material: PERMEX Synthetic Rubber Diaphragm
- Operation: Manual
- MPN: ROYAL 997-1.0-RB
- Certifications: ADA, Buy American Act, IAPMO, ASSE-1037
- Fixture Served: Urinal
- Body Style: Concealed
- Spud Connection: Top Spud
- Rough-In (in): 13.5"
- L Dimension (in): 2"-10-3/4"
- Volume per Flush (gal): 1.0
- Dual Flush: No
- Finish: Unfinished (Rough Brass)
- Vandal Resistant: Yes
- Min Operating Pressure (PSI): 15
- Max Operating Pressure (PSI): 80
Dimensions
| Inlet Size | 3/4" | — | — |
Details
| Series | ROYAL 997 | Device Type | Flushometer |
| Body Material | Semi-Red Brass | Seat Material | PERMEX Synthetic Rubber Diaphragm |
| Operation | Manual | Options | 2"-10-3/4" L Dimension (LDIM) |
| Fixture Served | Urinal | Body style | Concealed |
| Coating | Unfinished (Rough Brass) | Cycle volume gal | 1.0 gal |
| Dual flush | No | L dimension in | 2"-10-3/4" |
| Operating pressure min psi | 15 PSI | Rough in in | 13.5" |
| Spud connection | Top Spud | Vandal resistant | Yes |
Certifications & Standards
| ADA | Buy American Act |
| IAPMO | ASSE-1037 |
