Sloan CX 8198 Concealed Sensor Urinal Flushometer, less Plate

The Sloan CX8198-0.5 is a sensor-operated piston-type flush valve for a urinal.

Sloan CX 8198 concealed sensor urinal flushometer with front access wall plate, no rear chase needed, and battery or hardwired power. ADA compliant.

Options on this configuration: LESS; PLATE. Sloan model number: CX8198-0.5. Sloan's own price-list description: CX8198-0.5 LESS PLATE.

Features

• Fixed volume piston with filtered O-ring bypass
• Front access wall plate requires no rear access plumbing chase
• Sensor activated, hands-free operation
• Battery operated with hardwired option
• Electronic override button
• low Battery indicator light
• vandal resistant wall plate
• Adjustable flush connection

Common Questions

What fixture and flush volume is this valve for?

Per Sloan's own spec, it serves a urinal.

Is this exposed or concealed, and does it need a wall box?

Concealed -- the body sits behind the wall, with only the cover or trim visible.

Specifications

• Type: Flushometer
• Operation: Sensor
• MPN: CX8198-0.5
• Fixture Served: Urinal
• Body Style: Concealed
• Vandal Resistant: Yes
