Sloan Standard SF-2950 0.5 GPM Battery-Powered Sensor Faucet, Polished Chrome, Below-Deck Manual Mixer

The Sloan SF-2950 is a Deck-mounted Standard sensor faucet powered by battery. It delivers 0.5 GPM through a multi-laminar (non-aerating) outlet. It includes a below deck manual mixing valve. Available in Polished Chrome. This model is certified lead-free for potable-water installations.

The Sloan Standard faucets are based on offering rugged and dependable cost-solutions for strict budgets. The SF-2950 is a battery powered, mid-body, single-hole deck mounted faucet that provides commercial durability and premium aesthetics at a reasonable cost. The SF-2950 faucet comes with a number of features, including filtered solenoid valve with serviceable strainer filter and adjustable infrared sensor range that make it a great addition to any commercial restroom. Additionally, the SF-2950 includes all necessary mounting hardware and includes four (4) AA-sized batteries.

Options on this configuration: 4" Trim Plate (4).

Features

• 4" Trim Plate, Battery Power Supply, Below Deck Manual Mixing Valve, Polished Chrome Finish, 0.5 gpm, Multi-Laminar Spray, Infrared Sensor
• Chrome Plated Finish
• 0.5GPM Flow Rate with multi-laminar flow
• Includes 4" Trim Plate for additional coverage of sink deck near spout
• Battery powered with 4AA batteries included
• Below deck manual mixing valve included for temperature setting and adjustment
• Adjustable Infrared Sensor Range
• 36” (914 mm) Long Sensor Cable
• 24” (610 mm) Long Flex Hose
• Filtered Solenoid Valve with serviceable Strainer Filter
• Includes Four (4) AA-size Batteries
• Includes appropriate Mounting Hardware
• 1 Year limited warranty

Common Questions

How is this faucet powered, and what ships in the box?

This faucet runs on battery power. Sloan states a battery life of 2 years 8,000 cycles/month. No transformer or wiring is required.

Is this single-hole or centerset, and does it need a trim plate?

This model installs in a single deck hole.

Which mixing valve does this use, and is it ASSE 1070 listed?

It includes a below deck manual mixing valve.

What is the flow rate, and is it WaterSense certified?

It delivers 0.5 GPM.

What sensor technology does it use, and can it be commissioned remotely?

This faucet uses an infrared sensor.

Specifications

• Type: Sensor Faucet
• Warranty: 1-Year Limited
• MPN: SF-2950-4-BAT-BDM-CP-0.5GPM-MLM-FCT
• Certifications: ADA, CALGreen, CEC, IAPMO, NSF-61, NYC 604.4, TAS, NSF-372
• Lead-Free: Yes
• Power Source: DC (Battery)
• Power Supply Detail: Battery (BAT)
• Battery Life: 2 years 8,000 cycles/month
• Run Time (s): 30
• Sensor Type: Infrared
• Centers: Single-Hole
• Trim Plate: 4"
• Mixing Valve: Below Deck Manual Mixing Valve
• Outlet Type: Multi-Laminar (Non-Aerating)
• Body Height: Mid
• Mount Type: Deck-Mount
• Finish: Polished Chrome
• Flow Rate (GPM): 0.5
