The Sloan DOLPHIN TYPE II CLASS A-1.0-CP is a manual piston-type flush valve for a urinal. It delivers 1.0 gallons per flush, with a top spud connection at an exposed body. It features a red brass body.
Dolphin Type II Class A exposed manual water closet flushometer with red brass body, cover, tailpiece and control stop. BAA compliant and UPC certified.
Options on this configuration: A. Sloan model number: DOLPHIN TYPE II CLASS A-1.0-CP. Sloan's own price-list description: DOLPH TYPE II CLASS A.
Features
- 1.0 gpf, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
- ¾" I.P.S. Screwdriver Bak-Chek™ Angle Stop with ½” Inlet Adapter
- Vandal Resistant Stop Cap
- Ground Joint Tailpiece
- ¾” Scored Outlet with ½” Offset (hose, clamps, and flush connection not furnished with valve)
- Flushometer does not require water pressure to positively shut off
- High Copper, Low Zinc Brass Castings for Dezincification Resistance
- Non-Hold-Open Handle and No External Volume Adjustment to Ensure Water Conservation
- Handle Packing, Stop Seat and Vacuum Breaker molded from PERMEX® Rubber
- Rubber Compound for Chloramine Resistance
- Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy
- Classification for Red Brass. Valve shall be in compliance to the applicable sections of ASSE 1037
Common Questions
- What fixture and flush volume is this valve for?
- Per Sloan's own spec, it serves a urinal, 1.0 gallons per flush, a top spud connection.
- Is this exposed or concealed, and does it need a wall box?
- Exposed -- the working parts are visible on the wall surface.
- Is this ADA, WaterSense, or ASSE 1037 listed?
- Yes -- Sloan lists it as ASSE-1037.
Specifications
-
Type: Flushometer
-
Body Material: Red Brass
-
Operation: Manual
-
Country of Origin: USA
-
MPN: DOLPHIN TYPE II CLASS A-1.0-CP
-
Certifications: Buy American Act, ASSE-1037
-
Fixture Served: Urinal
-
Body Style: Exposed
-
Spud Connection: Top Spud
-
Volume per Flush (gal): 1.0
-
Dual Flush: No
-
Finish: Polished Chrome
-
Vandal Resistant: Yes
-
Min Operating Pressure (PSI): 15
-
Max Operating Pressure (PSI): 80
