Sloan MCR-282 MCR-282 USB Port Connector for PWT Management Console

The Sloan MCR-282 is a management console, a Sloan Valve genuine replacement part.

The MCR-282 USB Port-Connector is used to connect Sloan PWT MCR Series Communicating Controllers to the Sloan PWT Management Systems. The USB Port- Connector installs into your Sloan PWT Management Systems USB ports and connects to the MCR Series Controllers using TP/FT-10 Free Topology Twisted Pair (ANSI/CEA-709.3). Removable spring clamp and screw terminal connectors included LED Indicators: Service (amber), Transmit (green), Receive (green). Sloan offers desktop and laptop PWT Management System options that come with different features and capabilities depending on your facilities needs. Regardless of which Management System you choose they call come with alerts for usage violations, alert logs and reports, and remote fixture activations and controls.

Features

• MCR-282 USB Port Connector for PWT Management Console
• Connects MCR-4001/MCR-4011 series Communicating Controllers
• U10 USB Network Interface connects to a TP/FT-10 Free Topology Twisted Pair (ANSI/CEA-709.3)
• Removable spring clamp and screw terminal connectors included LED Indicators: Service (amber), Transmit (green), Receive (green)

Common Questions

What flush valves does this part fit?

Sloan's own parts data does not name a specific series for this exact code. Confirm fit against your flushometer's model number before ordering, or contact CSG to verify.

Is this a genuine Sloan part?

Yes. The MCR-282 is a factory-original Sloan Valve Company replacement part, not an aftermarket equivalent.

Specifications

• MPN: MCR-282
• Certifications: NOM
• Product Role: Management Console
• Accessory Type: Management Console
