- Enhanced camera functionality - TruSense technology with High Dynamic Range (HDR) sensor and TiltSense inclinometer give crisp, always upright images and feedback on camera angle in-pipe
- Interchangeability - Easily interchangeable D2 drums for on-the-job flexibility and compatible with all SeeSnake monitors
- Pushability - Drums feature different push cable lengths, diameters, stiffness, and springs for customizable jobs
- Portability - Multi-functional pull handle and smooth wheels for easy transport and positioning
- Increased storage - New taller stowbins with increased internal capacity to store jobsite essentials
- FEATURES
- SPECS
- INCLUDES
- SUPPORT DOCUMENTS
- VIDEO
- Enhanced camera functionality - TruSense technology with High Dynamic Range (HDR) sensor and TiltSense inclinometer give crisp, always upright images and feedback on camera angle in-pipe
- Interchangeability - Easily interchangeable D2 drums for on-the-job flexibility and compatible with all SeeSnake monitors
- Pushability - Drums feature different push cable lengths, diameters, stiffness, and springs for customizable jobs
- Portability - Multi-functional pull handle and smooth wheels for easy transport and positioning
- Increased storage - New taller stowbins with increased internal capacity to store jobsite essentials
Length
535 mm (21.0 in)
Width
345 mm (13.6 in)
Height
610 mm (24 in)
Drum Diameter
432 mm (17 in)
Camera Diameter
25 mm (1 in)
Camera Type
Self-leveling with TruSense
Camera Resolution
640 x 480
Spring Type
Single
Spring Length
316 mm (12.4 in)
Line Capacity
38 mm - 203 mm (1.5 in - 8 in)
70758
SeeSnake D2A Drum (200') with Self-Leveling Camera powered with TruSense
70763
SeeSnake D2B Drum (165') with Self-Leveling Camera powered with TruSense
44038
rM200 Stow Bins
17553
Spanner Wrench, 25mm
35338
45 mm Pipe Guide, 25 mm Camera, Pkg of 2
40598
60 mm Pipe Guide, 25 mm Camera, Pkg of 2
46708
85 mm Pipe Guide, 25 mm Camera, Pkg of 2
46713
125 mm Pipe Guide, 25 mm Camera, Pkg of 2
47793
36 mm Pipe Guide, 25 mm Camera, Pkg of 1
63868
Various Pipe Guides, 25mm Camera Head
66483
RIDGID CS6x Versa Carrying Case
FEATURES
SPECIFICATIONS
Length
535 mm (21.0 in)
Width
345 mm (13.6 in)
Height
610 mm (24 in)
Drum Diameter
432 mm (17 in)
Camera Diameter
25 mm (1 in)
Camera Type
Self-leveling with TruSense
Camera Resolution
640 x 480
Line Capacity
38 mm - 203 mm (1.5 in - 8 in)
Push Cable Length
61 m (200 ft)
Push Cable Diameter
7.5 mm (0.3 in)
Spring Type
Through die head
INCLUDES
70758
SeeSnake D2A Drum (200') with Self-Leveling Camera powered with TruSense
70763
SeeSnake D2B Drum (165') with Self-Leveling Camera powered with TruSense
44038
rM200 Stow Bins
17553
Spanner Wrench, 25mm
35338
45 mm Pipe Guide, 25 mm Camera
Pack of 2
40598
60 mm Pipe Guide, 25 mm Camera
Pack of 2
46708
85 mm Pipe Guide, 25 mm Camera
Pack of 2
46713
125 mm Pipe Guide, 25 mm Camera
Pack of 2
47793
36 mm Pipe Guide, 25 mm Camera
Pack of 1
63868
Various Pipe Guides, 25mm Camera Head
66483
RIDGID CS6x Versa Carrying Case
SUPPORT DOCUMENTS
VIDEOS
ABOUT RIDGID SEESNAKE
MACHINE POWER
SeeSnake reels vary in reach, stiffness and optimal pipe size
SeeSnake reels are designed with different capabilities in the distance they can reach inside the pipe and the pipe sizes they execute better. For larger pipes and stiffer cables look at the Ridgid Standard and the rM200B, followed by the Compact M40, the Mini model and the rM200A, and then by the Compact C40, Compact2, and microReel.
SUPERIOR VIDEO QUALITY
Up your game with the new TruSense cameras
RIDGID has advanced drain inspection equipment. TruSense cameras are designed to offer superior video quality and to capture relevant data. They feature HDR video clarity and on-camera TiltSense inclinometers that measure the degree of tilt. Find TruSense cameras in the Compact C40, Compact M40, the Mini and Standard reels.
HIGH RESOLUTION MONITORS
Monitors record in high resolution and feature larger screens
Besides displaying video, monitors work as the main control board to operate and manage settings, data capturing, video set up and camera control. Quality in software and hardware vary among monitors. Higher resolution and larger screen monitors are the CS12x Monitor followed by the CS6x Versa monitors.
RIDGID SeeSnake Drain Inspection
If having the best quality equipment for drain inspection jobs is what you are after, Ridgid SeeSnake equipment is what you need. With reels varying in reach and in video quality capabilities, there are certain models that will work better for you than others.
RIDGID SeeSnake Drain Inspection
If having the best quality equipment for drain inspection jobs is what you are after, Ridgid SeeSnake equipment is what you need. With reels varying in reach and in video quality capabilities, there are certain models that will work better for you than others.
CAMERAS & MONITORS
SEESNAKE MONITORS
CAMERAS & MONITORS
SEESNAKE MONITORS
All Ridgid SeeSnake monitors are equipped with wi-fi connectivity.
All SeeSnake monitors integrate seamlessly with every SeeSnake reel.
The CS12x has the largest screen and resolution, longest battery life and most powerful processor.
The CS6x Versa is the flexible, efficient solution. It works with all reels and easily docks to the Compact series reels.
