RIDGID 82138 SeeSnake Compact M40 DSL Reel Only with Digital Self-Leveling Camera, TruSense

The RIDGID 82138 is a SeeSnake Compact M40 camera reel with 131 ft of push cable and a 25 mm self-leveling camera head, for 1-1/2" to 8" lines. This is the reel only, with no monitor included. It is a TruSense model. The built-in 512 Hz sonde lets a locator trace the camera head in the line.

Common Questions

Which monitor works with this reel?

The M40 DSL has a quick-release docking system for the SeeSnake CS6x VERSA monitor and works with the SeeSnake CSx Via and HQx Dock as a bring-your-own-screen streaming solution. You can also view and record on a phone or tablet with the free HQx Live app.

What pipe sizes can it inspect?

RIDGID lists a line capacity of 1-1/2" to 8" and 131 ft of push cable (0.36" (9.1 mm) diameter).

Does it include a sonde so I can locate the camera?

Yes. The camera head has a built-in 512 Hz sonde. Trace it with a RIDGID receiver that lists a 512 Hz sonde frequency, such as the SeekTech SR-20 or SR-24LE.

Specifications

• Type: Camera Reel
• Country of Origin: United States
• MPN: 82138
• Pipe Size Range: 1-1/2" to 8"
• Push Cable Length (ft): 131
• Push Cable Diameter: 0.36" (9.1 mm)
• Camera Head (mm): 25
• Self-Leveling: Yes
• Display: None (reel only)
• Sonde Frequency (Hz): 512
• Waterproof Rating: IPx5 (without monitor)
