Spartan Tool 1/4" Closed Nozzle, 1,500 PSI @ 2.2 GPM 71108300

The Spartan Tool 1/4" 30-Deg Closed Nozzle is a closed sewer jetter nozzle for 1/4" jetting hose, rated 1,500 PSI at 2.2 GPM, matched to the Model 717.

The Spartan Tool 1/4" 30-Deg Closed Nozzle (71108300) is designed for high-performance sewer and drain cleaning, delivering superior efficiency and reliability. This nozzle is specifically engineered to optimize the cleaning process by ensuring maximum reach and effective debris removal. Ideal for professional use, the 30-Deg Closed Nozzle offers exceptional cornerability, making it a valuable tool for tackling multiple bend pipes and general cleaning tasks.

Features

• Optimized
• Angle : 30-degree orifice angle provides enhanced cornerability, allowing the nozzle to navigate multiple bend pipes effortlessly
• Pressure : Operates at a maximum pressure of 1500 PSI, ensuring powerful cleaning performance
• Efficient
• Rate : Delivers a flow rate of 2.2 GPM, balancing effective cleaning with water efficiency
• Construction : Built with high-quality materials to withstand the demands of professional sewer and drain cleaning
• Reach : Closed design is ideal for pulling the hose further down the line, maximizing the cleaning range
• Versatile

Common Questions

What hose or thread size does this nozzle need?

This nozzle is sized for 1/4" jetting hose with NPT threads.

Which Spartan Tool machines does this fit?

Spartan Tool lists this as matched to the Model 717.

Is this the closed or open version?

This is the Closed pattern. Closed nozzles concentrate the jet for long-distance penetration; Open nozzles spread it wider for initial penetration of soft deposits. Check your job before ordering the open pair.

What pressure and flow is this nozzle rated for?

This nozzle is rated 1,500 PSI at 2.2 GPM. Running it well above or below this rating changes the jet pattern and can shorten its life.

Specifications

• Type: Closed
• Hose Size: 1/4"
• Connection: NPT
• MPN: 71108300
• Rated Pressure (PSI): 1500
• Flow Rate (GPM): 2.2
• Jet Angle (deg): 30
• Fits Models: Model 717
